860 lb. load capacity – ideal for residential and light commercial use
Galvanized steel framework and rail system built for durability and corrosion resistance
Custom aluminum carriage (46” x 59”) with non-skid decking and bench seating
Choice of entry/exit options: side-entry or wheelchair-accessible
Four standard powder coat color options + custom colors available
Smooth and quiet drum drive system for hills up to 130 ft
Remote, wireless, and carriage-mounted controls for convenience
Optional landing gates with ASME-compliant interlocks
Spring buffer system in line with ASME A17.1-2016 safety standards
Over-speed governor and slack cable safety system for enhanced protection
Reliable hillside access: Perfect for waterfront homes, sloped properties, and elevated decks
Customizable design: Tailor your elevator to match your home’s style and functional needs
Safe and compliant: Built with modern safety mechanisms and industry-approved materials
Weather-resistant: Powder-coated aluminum and galvanized steel components ensure longevity in harsh marine environments
Smooth operation: Soft start/stop technology provides a comfortable ride every time
Model: CAH860 Classic Advantage
Drive Type: Drum Drive
Load Capacity: 860 lbs
Rail System: 2” x 5” 11-gauge galvanized tubing, 41.5” outside rail width
Carriage Size: 46” x 59”, aluminum tubing with non-skid aluminum floor
Cable: Galvanized aircraft cable – 1/4” (7,000 lb strength) or 5/16” (9,800 lb strength)
Motor: 3 or 5 HP AC Drive
Travel Speed: 70 feet per minute
Control Panel: UL-listed E473065, NEMA 4 waterproof enclosure
Bucky Lift provides expert installation of the Marine Innovation CAH860 system. Our team will:
Cement support posts into the ground for a secure base
Assemble and bolt the galvanized rail system on-site
Customize carriage placement, gate entry, and wiring per your property’s layout
Test all safety mechanisms and ensure code compliance
Offer setup for optional features such as carriage canopies, cab lighting, and battery charging docks
Over-speed governor activates automatic braking system
Slack cable detection automatically shuts down the lift
Spring buffers and interlocked landing gates meet ASME A17.1-2016 code
Emergency stop (E-stop) controls at top, bottom, and on the carriage
Lock-out key and remote control for secure, restricted use
Marine Innovations Residential Incline Elevator Warranty
Marine Innovations, Inc. offers a limited warranty on their residential incline elevators to the original owner. Coverage includes:
1 Year on all electrical parts and components
1 Year on the drive and brake cable
3 Years on all non-structural components (gearbox, motor, brakes, etc.)
15 Years on all structural components
Bucky Lift offers scheduled maintenance services for the CAH860– Classic Advantage incline elevator. Regular inspections and upkeep help ensure long-term performance and safe operation.
Contact Bucky Lift to learn more about available service plans or to schedule maintenance for your CAH860 system.
Starting from
Installation Included
